Ameritool Micro gas springs are a miniature and compact option with a rod diameter of just .1875” and a tube diameter of only .500”. These are designed to fit in the smallest of applications. These gas springs have a force range between 5 and 30 pounds (22 N – 133 N) and feature stroke lengths between 0.5 and 3.0 inches.
Micro gas springs are high quality and long-lasting gas springs. These micro gas springs are made from 316 stainless steel with a chrome plated 316 stainless steel rod for excellent corrosion resistance.
These are ideal for applications where space is very limited.
| SKU | Rod Diameter (A) | Body Diameter (B) | Stroke (C) | Compressed Length (D) | Extended Length (E) | Male Thread | Min Max Lifting Force – # (N) |
|---|---|---|---|---|---|---|---|
|
SKU
|
Rod Diameter (A)
0.19 (4.8)
|
Body Diameter (B)
0.500 (12.7)
|
Stroke (C)
0.5 (12.7)
|
Compressed Length (D)
1.78 (45.2)
|
Extended Length (E)
2.28 (57.9)
|
Male Thread
M4 x 0.7
|
Min Max Lifting Force – # (N)
5-30 (22-133)
|
|
SKU
|
Rod Diameter (A)
0.19 (4.8)
|
Body Diameter (B)
0.500 (12.7)
|
Stroke (C)
1.0 (25.4)
|
Compressed Length (D)
2.28 (57.9)
|
Extended Length (E)
3.28 (83.3)
|
Male Thread
M4 x 0.7
|
Min Max Lifting Force – # (N)
5-30 (22-133)
|
|
SKU
|
Rod Diameter (A)
0.19 (4.8)
|
Body Diameter (B)
0.500 (12.7)
|
Stroke (C)
1.5 (38.1)
|
Compressed Length (D)
2.78 (70.6)
|
Extended Length (E)
4.28 (108.7)
|
Male Thread
M4 x 0.7
|
Min Max Lifting Force – # (N)
5-30 (22-133)
|
|
SKU
|
Rod Diameter (A)
0.19 (4.8)
|
Body Diameter (B)
0.500 (12.7)
|
Stroke (C)
2.0 (50.8)
|
Compressed Length (D)
3.28 (83.3)
|
Extended Length (E)
5.28 (134.1)
|
Male Thread
M4 x 0.7
|
Min Max Lifting Force – # (N)
5-30 (22-133)
|
|
SKU
|
Rod Diameter (A)
0.19 (4.8)
|
Body Diameter (B)
0.500 (12.7)
|
Stroke (C)
2.5 (63.5)
|
Compressed Length (D)
3.78 (96.0)
|
Extended Length (E)
6.28 (159.5)
|
Male Thread
M4 x 0.7
|
Min Max Lifting Force – # (N)
5-30 (22-133)
|
|
SKU
|
Rod Diameter (A)
0.19 (4.8)
|
Body Diameter (B)
0.500 (12.7)
|
Stroke (C)
3.0 (76.2)
|
Compressed Length (D)
4.28 (108.7)
|
Extended Length (E)
7.28 (184.9)
|
Male Thread
M4 x 0.7
|
Min Max Lifting Force – # (N)
5-30 (22-133)
|
Notes:
<describe why they would want to see fixed vs adjustable?>.
We can make custom designed springs, contact us for design assistance.
